SCPI Reference Tables 17-13
Table 17-9
TRIGger command summary
Command Description
Default
parameter
Ref SCPI
:INITiate Path to initiate measurement cycle(s): Sec 9 √
[:IMMediate] Initiate one trigger cycle. √
:ABORt Reset trigger system (goes to idle state). √
:ARM[:SEQuence[1]] Path to configure arm layer: √
[:LAYer[1]]
:SOURce <name> Select control source; IMMediate, TIMer, BUS,
TLINk, STESt, PSTest, NSTest, BSTest, or
MANual.
IMMediate √
:SOURce? Query arm control source. √
:COUNt <n> Set measure count; 1 to 2500, or INF (infinite). 1 √
:COUNt? Query measure count. √
:TIMer <n> Set timer interval; 0.001 to 99999.999 (sec). 0.100 √
:TIMer? Query timer interval. √
[:TCONfigure] √
:DIRection <name> Enable (SOURce) or disable (ACCeptor)
bypass.
ACCeptor √
:DIRection? Query arm source bypass. √
[:ASYNchronous] Configure input/output triggers:
:ILINe <NRf> Select input trigger line; 1, 2, 3, 4, 5, or 6. 1
:ILINe? Query input trigger line.
:OLINe <NRf> Select output trigger line; 1, 2, 3, 4, 5, or 6. 2
:OLINe? Query output trigger line.
:OUTPut <name> Output trigger (TRIGger) or not at all
(NONE).
NONE
:OUTPut? Query output trigger status.
:TRIGger[:SEQuence[1]] Path to configure trigger layer: √
:SOURce <name> Select control source; IMMediate or TLINk. IMMediate √
:SOURce? Query trigger control source. √
:COUNt <n> Set measure count; 1 to 2500, or INF (infinite). 1 √
:COUNt? Query measure count. √
:DELay <n> Set trigger delay; 0 to 999.9999 (sec). 0.0 √
:AUTO <b> Enable or disable auto delay. OFF √
:AUTO? Query state of auto delay. √
:DELay? Query delay value. √
