SourceMeter
®
Line Specifications
SYSTEM SPEEDS
1
Reading rates applicable for voltage or current measurements. Auto zero off, autorange
off, filter off, display off, trigger delay = 0, and binary reading format.
2
Purely resistive lead. 1µA and 10µA ranges <65ms.
3
1000 point sweep was characterized with the source on a fixed range.
4
Pass/Fail test performed using one high limit and one low math limit.
5
Includes time to re-program source to a new level before making measurement.
6
Time from falling edge of START OF TEST signal to falling edge of END OF TEST signal.
7
Command processing time of :SOURce:VOLTage|CURRent:TRIGgered <nrf> command
not included.
NOISE REJECTION:
NPLC NMRR CMRR
Fast 0.01 — 80 dB
Medium 0.1 — 80 dB
Slow 1 60 dB 100 dB
1
1
Except lowest 2 current ranges = 90dB.
LOAD IMPEDANCE: Stable into 20,000pF typical.
DIFFERENTIAL MODE VOLTAGE:
2400: 250 V Pk
2410: 1100 V Pk
2420: 75 V Pk
2425, 2430: 125 V Pk
2440: 42 V Pk
COMMON MODE VOLTAGE: 250V DC (40V DC for Model 2440).
COMMON MODE ISOLATION: >10
9
Ω, <1000pF.
OVERRANGE: 105% of range, source and measure.
MAX.VOLTAGE DROP BETWEEN INPUT/OUTPUT AND SENSE TERMINALS: 5V.
MAX. SENSE LEAD RESISTANCE: 1MΩ for rated accuracy.
SENSE INPUT IMPEDANCE: >10
10
Ω.
GUARD OFFSET VOLTAGE: <150µV, typical (300µV for Models 2430, 2440).
SOURCE OUTPUT MODES:
Pulse (Model 2430 only)
Fixed DC level
Memory List (mixed function)
Stair (linear and log)
SOURCE MEMORY LIST: 100 points max.
MEMORY BUFFER:
5,000 readings @ 5 digits (two 2,500 point buffers). Includes selected
measured value(s) and time stamp. Lithium battery backup (3 yr+ battery life).
PROGRAMMABILITY: IEEE-488 (SCPI-1995.0), RS-232, 5 user-definable power-up
states plus factory default and *RST.
DIGITAL INTERFACE:
Output Enable: Active low input.
Handler Interface: Start of test, end of test, 3 category bits. +5V@ 300mA supply.
Digital I/O: 1 trigger input, 4 TTL/Relay Drive outputs (33V @ 500mA, diode
clamped).
POWER SUPPLY: 100V to 240V rms, 50–60Hz (automatically detected at power up).
Model 2400: 190VA. Model 2410: 210VA. Model 2420: 220VA. Model 2425, 2430:
250VA. Model 2440: 240VA.
COOLING: (Model 2410, 2420, 2425, 2430, 2440): Forced air, variable speed.
WARRANTY: 1 year.
EMC: Conforms to European Union Directive 89/336/EEC, EN 61326-1.
SAFETY: Conforms to European Union Directive 73/23/EEC, EN61010-1.
VIBRATION: MIL-PRF-28800F Class 3 Random.
WARM-UP: 1 hour to rated accuracies.
DIMENSIONS: 89mm high × 213mm wide × 370mm deep (3
1
⁄
2
in × 8
3
⁄
8
in × 14
9
⁄
16
in).
Bench Configuration (with handle & feet):104mm high × 238mm wide × 370mm
deep (4
1
⁄
8
in × 9
3
⁄
8
in × 14
9
⁄
16
in).
WEIGHT: 3.21kg (7.08 lbs) (Model 2425, 2430, 2440: 4.1kg, 9.0 lbs).
ENVIRONMENT:
For Indoor Use Only: Maximum 2000m above Sea Level
Operating: 0°–50°C, 70%R.H. up to 35°C. Derate 3% R.H./°C, 35°–50°C.
Storage: –25°C to 65°C.
ACCESSORIES SUPPLIED: Model 1754 Universal Test Lead Kit, User’s Manual,
Service Manual, LabVIEW and TestPoint Drivers.
Specifications subject to change without notice.
SourceMeter
®
is a registered trademark of Keithley Instruments, Inc. All other trademarks are the property of their respective companies.
GENERAL
HW Rev. B
4/30/02
2400, 2400-C,2410, 2410-C,
2420, 2420-C,2425, 2425-C,
2430, 2430-C,2440, 2440-C
MEASUREMENT
1
MAXIMUM RANGE CHANGE RATE: 75/second.
MAXIMUM MEASURE AUTORANGE TIME: 40ms (fixed source)
2
.
SWEEP OPERATION
3
READING RATES (rdg./second) for 60Hz (50Hz):
SOURCE-MEASURE
MEASURE SOURCE-MEASURE
5
PASS/FAIL TEST
4, 5
SOURCE-MEMORY
4
SPEED NPLC/TRIGGER ORIGIN TO MEM. TO GPIB TO MEM. TO GPIB TO MEM. TO GPIB TO MEM. TO GPIB
Fast 0.01 / internal 2081 (2030) 1754 1551 (1515) 1369 902 (900) 981 165 (162) 165
IEEE-488.1 Mode 0.01 / external 1239 (1200) 1254 1018 (990) 1035 830 (830) 886 163 (160) 163
Fast 0.01 / internal 2081 (2030) 1198 (1210) 1551 (1515) 1000 (900) 902 (900) 809 (840) 165 (162) 164 (162)
IEEE-488.2 Mode 0.01 / external 1239 (1200) 1079 (1050) 1018 (990) 916 (835) 830 (830) 756 (780) 163 (160) 162 (160)
Medium 0.10 / internal 510 (433) 509 (433) 470 (405) 470 (410) 389 (343) 388 (343) 133 (126) 132 (126)
IEEE-488.2 Mode 0.10 / external 438 (380) 438 (380) 409 (360) 409 (365) 374 (333) 374 (333) 131 (125) 131 (125)
Normal 1.00 / internal 59 (49) 59 (49) 58 (48) 58 (48) 56 (47) 56 (47) 44 (38) 44 (38)
IEEE-488.2 Mode 1.00 / external 57 (48) 57 (48) 57 (48) 57 (47) 56 (47) 56 (47) 44 (38) 44 (38)
SINGLE READING OPERATION READING RATES (rdg./second) for 60Hz (50Hz):
MEASURE SOURCE-MEASURE
5
SOURCE-MEASURE PASS/FAIL TEST
4,5
SPEED NPLC/TRIGGER ORIGIN TO GPIB TO GPIB TO GPIB
Fast (488.1) 0.01 / internal 537 140 135
Fast (488.2) 0.01 / internal 256 (256) 79 (83) 79 (83)
Medium(488.2) 0.10 / internal 167 (166) 72 (70) 69 (70)
Normal (488.2) 1.00 / internal 49 (42) 34 (31) 35 (30)
COMPONENT INTERFACE HANDLER TIME for 60Hz (50Hz):
4, 6
MEASURE SOURCE SOURCE-MEASURE PASS/FAIL TEST
5, 7
SPEED NPLC/TRIGGER ORIGIN TO GPIB PASS/FAIL TEST TO GPIB
Fast 0.01 / external 1.04 ms (1.08 ms) 0.5 ms (0.5 ms) 4.82 ms (5.3 ms)
Medium 0.10 / external 2.55 ms (2.9 ms) 0.5 ms (0.5 ms) 6.27 ms (7.1 ms)
Normal 1.00 / external 17.53 ms (20.9 ms) 0.5 ms (0.5 ms) 21.31 ms (25.0 ms)
