Kenwood eXcelon KDC-X991 User Manual

20
|
English
General features
Display Type E
G-Analyzer display Selection
Changing the G-Analyzer display.
⁄
• Before alternating G-Analyzer display, you are required to
setup <G-Counter Level setting> (page 22), <G-Analyzer
Calibration setup> (page 22), <G-Analyzer vehicle weight
setup> (page 23) and <G-Analyzer vehicle class setup>
(page 23).
1 Enter G-Analyzer display selection mode
Using the Control knob, select "DISPLAY" > "G-
MENU".
For the operation method, refer to <Function
Control mode> (page 11).
Display Type E
G-Analyzer Stop Watch
The control of stop watch can be started by G-
Analyzer function.
¤
• Do not use G-Analyzer stop watch on the Public roads.
1 Enter G-Analyzer Stop Watch mode
Using the Control knob, select "DISPLAY" >
"GMA" > "S.WATCH".
For the operation method, refer to <Function
Control mode> (page 11).
"STOP WATCH" is displayed.
2 Make the counter ready
Press the Control knob.
"Ready" is displayed.
Display Type C
Icon Display Switching
Changing the Icon Display.
1 Enter Icon select mode
Using the Control knob, select "DISPLAY" >
"SIDE".
2 Switch the Icon display
Turn the Control knob or push it towards left
or right.
Select from the following displays:
Icon display Display
Source graphic "Source"
Text label "Text"
Album art (iPod or "Music Editor" media) "Photograph"
3 Exit Icon select mode
Press the Control knob.
⁄
• The Album art display function is not used to display the
image corresponding to the tag recorded in the Audio
file.
• If Album art display is selected during playback of an
iPod or "Music Editor" media on which no album art is
recorded, a source icon is displayed.
• During Album art downloading, "Down-loading" is
displayed. Downloading requires a maximum of 30
seconds.
2 Select the G-Analyzer display
Turn the Control knob.
Select from the following displays.
G-Force Sensor display
G- Graphic display
G-Counter display
⁄
• G-Graphic display
- Graphic: Displays the condition of G in horizontal
direction (e.g; when turning the curve) by the graphic.
- Text: The maximum value of acceleration G, right
direction G, and left direction G is displayed by the
numerical value. The value of G is only the reference, so
is different from the actual value.
• G-Counter display
Adds the point of the acceleration level. The point is
determined after a lapse of 1 hr drive or at power off
(ACC Off), and then it will be displayed by the graph.
Furthermore, the G-Counter displays the average of the
past data by the line. (The scale of graph is determined
along with the largest point among the past 10 data.)
• The value of G-Meter display and G-Counter display can
be reset by <G-Analyzer Reset> (page 22).
3 Exit G-Analyzer display selection mode
Press the Control knob.
B64-3767-0000KEnglish.indd20B64-3767-0000KEnglish.indd20 07.5.102:15:47PM07.5.102:15:47PM

Kenwood eXcelon KDC-X991 Specifications

FM Tuner Section

frequency range	87.9 MHz – 107.9 MHz
usable sensitivity	9.3 dBf (0.8 μV/75 Ω)
quieting sensitivity	15.2 dBf (1.6 μV/75 Ω)
frequency response	30 Hz – 15 kHz
signal to noise ratio (MONO)	70 dB
selectivity	≥ 80 dB
stereo separation	40 dB

AM Tuner Section

frequency range	530 kHz – 1700 kHz
usable sensitivity	28 dBμ (25 μV)

CD Player Section

spindle speed	1000 – 400 rpm (CLV 2times)
frequency response	10 Hz – 20 kHz
total harmonic distortion	0.008 %
signal to noise ratio	110 dB
dynamic range	93 dB

USB Interface

usb standard	USB 1.1/ 2.0
maximum supply current	500 mA
file system	FAT16/ 32

Audio Section

maximum output power	50 W x 4
full bandwidth power	22 W x 4
speaker impedance	4 – 8 Ω
tone action band 1	60 – 200 Hz ±9 dB
tone action band 2	250 – 1k Hz ±9 dB
tone action band 3	1.25k – 4k Hz ±9 dB
tone action band 4	5k – 16k Hz ±9 dB
preout level / load	5000 mV/10 kΩ
preout impedance	≤ 80 Ω

Auxiliary Input

frequency response	20 Hz – 20 kHz
input maximum voltage	1200 mV
input impedance	100 kΩ

General

operating voltage	14.4 V
current consumption	10 A
installation size	182 x 53 x 155 mm
weight	3.31 lbs (1.5 kg)
