English
|
21
Display Type E
G-Analyzer Horsepower Analysis
This measures the horsepower and displays graph
and max power. It automatically saves the highest
record.
¤
• Do not use G-Analyzer Horsepower Analysis on the
Public roads.
• Do not use this product in any way that prevents you
from driving safely.
• Follow all driving laws and use common sense when
using this product.
⁄
• Before alternating G-Analyzer Horsepower Analysis, you
are required to setup <G-Analyzer vehicle weight setup>
(page 23) and <G-Analyzer vehicle class setup> (page
23).
1 Enter G-Analyzer Horsepower Analysis mode
Using the Control knob, select "DISPLAY" >
"GMA" > "HP".
For the operation method, refer to <Function
Control mode> (page 11).
"HORSEPOWER" is displayed.
Previous max power and record are displayed.
2 Begin measurement
Press the Control knob.
"Ready" is displayed.
3 Start the car
"Measure" is displayed.
After 15 seconds of measurement, the result is
displayed.
Display the result
The graph shows the variation in horsepower
between 0.1 to 15.0 seconds. The maximum power
is displayed in red and the markings provided at
intervals of 5 seconds are displayed in blue.
¤
• Pressing the Control knob also begins the measurement.
To prevent danger, push the control knob before starting
the car.
4 To display the maximum power in the section
Push the Control knob towards right or left.
Each time you push the Control knob, the
maximum power in the section is displayed.
5 Exit G-Analyzer Horsepower Analysis mode
Press the [FNC] button.
⁄
• Like your vehicle’s speedometer, G-Analyzer is no more
than a measuring function. The HP or G value measured
by this unit may not be completely accurate due to its
simplified method of measurement. The G-Analyzer is
only for reference and should not be used to confirm the
horsepower specifications of your vehicle.
• Measuring after starting the car lowers the accuracy.
• The record will not be renewed if the measurement is
discontinued.
• The graph’s scale adjusts automatically to the
horsepower value.
• The value of max power and record can be reset by <G-
Analyzer Reset> (page 22).
3 Start Count
When G in the vertical direction is detected during
the travel, the count automatically starts.
"Running" is displayed.
⁄
• You can also start the counter by pressing the Control
knob.
4 Stop Count
Press the Control knob.
"Stop" is displayed.
⁄
• The control will start again when you accelerate or press
the Control knob.
Do the operation after step 2.
When you Reset the Count
(While "Stop" is displayed)
Press the Control knob for at least 1 second.
⁄
• You can reset of count when the count is stopped.
5 Exit G-Analyzer Stop Watch mode
Press the [FNC] button.
⁄
• When Power off (ex; ACC OFF) while counting, the value
of 1 second or less will be "00".
B64-3767-0000KEnglish.indd21B64-3767-0000KEnglish.indd21 07.5.102:15:48PM07.5.102:15:48PM
