Page #33 background imageLoading...
Page #33 background image
English
|
33
Play function of CD and Audio file
Setting up the Repeat Play and Scan Play.
1 Set up the play function
Using the Control knob, set your desired setup
item to On/Off.
For the operation method, refer to <Function
Control mode> (page 11).
When the play function is turned on, “ON” is
displayed.
Display Icon Function
"File Scan" "SCAN" Successively plays the audio files in the
current folder or genre.
"Folder RDM" "RANDOM" Plays the audio files in the current folder
or genre at random.
"All Random" "ALL RDM" Plays the audio files in the current disc,
USB device or Internal Memory at random.
"File Repeat" "FILE REP" Plays the current audio file repeatedly.
"Folder Repeat" "FOLDER
REP"
Plays the audio files in the current folder
or genre repeatedly.
"(Track) Scan" "SCAN" Plays the beginnings of the music on the
current CD/MD one after another for 10
seconds each.
"Disc Random" "RANDOM" Plays the music on the current CD/MD
at random.
"Magazine RDM""M.RDM" Plays the music in the disc changer at
random.
"(Track) Repeat" "TRACK REP"Plays the current music on the current
CD/MD repeatedly.
"Disc Repeat" "DISC REP" Plays the music on the current CD/MD
repeatedly.
2 Select an option for the selected item
Press the Control knob.
Pressing the Control knob switches between
options.
3 Exit Play Function Set mode
Press the [FNC] button.
Only the icons available to the current source are
displayed.
Location played with "File Scan"
- Audio file: First 10 seconds
- Music Editor media: First 10 seconds or the part picked
by Intro Skip (30 seconds)
During Intro Skip, turn the control knob left or right to
change the song.
The scan method depends on the Music Editor setting.
See the Music Editor help for details.
During random play, turn the control knob right to
randomly select the next song.
Function of Audio file
File Select
Selecting the music you want to listen to from the
device or media being played now.
1 Enter File Select mode
Turn the Control knob.
2 Search for music
Select the category item using the Control
knob.
Operation system for iPod
Operation type Operation
Movement between items Turn the Control knob.
Selection of item Press the Control knob.
Return to previous item Push the Control knob towards up.
Return to first item Push the Control knob towards up for at least
1 second.
Operation system for other than iPod
Operation type Operation
Movement between items Turn the Control knob.
Selection of item Push the Control knob towards right.
Return to previous item Push the Control knob towards left.
Return to first item Push the Control knob towards left for at least
1 second.
The "2" or "3" symbol shown beside the displayed
item indicates that the item is preceded or followed
by another item.
Selecting a music will play it from the beginning.
Cancelling File Select
Press the [FNC] button.
Even when the iPod is connected, you can change the
operation method from <Operation method for iPod> to
<Operation method for other than iPod>. Refer to <iPod
mode Setting> (page 46).
B64-3767-0000KEnglish.indd33B64-3767-0000KEnglish.indd33 07.5.102:15:55PM07.5.102:15:55PM

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kenwood eXcelon KDC-X991 and is the answer not in the manual?

Kenwood eXcelon KDC-X991 Specifications

FM Tuner Section IconFM Tuner Section
frequency range87.9 MHz – 107.9 MHz
usable sensitivity9.3 dBf (0.8 μV/75 Ω)
quieting sensitivity15.2 dBf (1.6 μV/75 Ω)
frequency response30 Hz – 15 kHz
signal to noise ratio (MONO)70 dB
selectivity≥ 80 dB
stereo separation40 dB
AM Tuner Section IconAM Tuner Section
frequency range530 kHz – 1700 kHz
usable sensitivity28 dBμ (25 μV)
CD Player Section IconCD Player Section
spindle speed1000 – 400 rpm (CLV 2times)
frequency response10 Hz – 20 kHz
total harmonic distortion0.008 %
signal to noise ratio110 dB
dynamic range93 dB
USB Interface IconUSB Interface
usb standardUSB 1.1/ 2.0
maximum supply current500 mA
file systemFAT16/ 32
Audio Section IconAudio Section
maximum output power50 W x 4
full bandwidth power22 W x 4
speaker impedance4 – 8 Ω
tone action band 160 – 200 Hz ±9 dB
tone action band 2250 – 1k Hz ±9 dB
tone action band 31.25k – 4k Hz ±9 dB
tone action band 45k – 16k Hz ±9 dB
preout level / load5000 mV/10 kΩ
preout impedance≤ 80 Ω
Auxiliary Input IconAuxiliary Input
frequency response20 Hz – 20 kHz
input maximum voltage1200 mV
input impedance100 kΩ
General IconGeneral
operating voltage14.4 V
current consumption10 A
installation size182 x 53 x 155 mm
weight3.31 lbs (1.5 kg)
