Kenwood eXcelon KDC-X991 User Manual

50
|
English
Auxiliary Input Display Setting &
Station/Disc Naming
Selecting the display when changing to Auxiliary
input source. For the Station/Disc Naming refer to
the <Station/Disc Naming (SNPS/DNPS)> (page 24).
1 Select Auxiliary input source
Press the [SRC] button.
Select the "AUX"/"AUX EXT" display.
Refer to <Selecting the Source> (page 8).
2 Enter Menu mode
Using the Control knob, select "MENU".
For the operation method, refer to <Function
Control mode> (page 11).
3 Select Auxiliary input display setting mode
Turn the Control knob.
Select the "Name Set" display.
4 Enter Auxiliary input display setting mode
Press the Control knob for at least 1 second.
The presently selected Auxiliary input display is
displayed.
5 Select the Auxiliary input display
Turn the Control knob or push it towards up or
down.
Each time you push the knob, the display alternates
as listed below.
• "AUX"/"AUX EXT"
• "DVD"
• "PORTABLE"
• "GAME"
• "VIDEO"
• "TV"
6 Exit Auxiliary input display setting mode
Press the [FNC] button.
⁄
• When operation stops for 10 seconds, the name at that
time is registered, and the Auxiliary input display setting
mode closes.
• The Auxiliary input display can be set only when the
built-in auxiliary input or the auxiliary input of optional
KCA-S220A is used.
Menu system
In HD Radio mode
Receive mode Setting
Sets the receive mode.
1 Select the Receive mode
Push the Control knob towards up or down.
Select the "Receive Mode" display.
2 Enter Receive mode
Press the Control knob for at least 1 second.
3 Set the Receive mode
Push the Control knob towards up or down.
Each time you push the knob, the Receive mode
alternates between the modes shown in the table
below.
Receive mode Display Operation
Auto mode "Auto"
Analog broadcasts and digital
broadcasts will be switched
automatically.
When both are being transmitted,
the digital broadcast will have
priority.
Digital "Digital" Digital broadcasts only.
Analog "Analog" Analog broadcasts only.
4 Exit Receive mode
Press the [FNC] button.
⁄
• Even if the Receive mode is set to "Auto", when the Ball
game mode program (non-delayed broadcast program)
is received, the Receive mode will automatically switch
to Analog broadcast only.
In Satellite radio source
Electronic Serial Number (ESN)
display
Displaying the Electronic Serial Number.
Display
"ESN=************"
⁄
• Electronic Serial Number (ESN)
It is important to retain the unit serial number and the
electronic Satellite radio Identification number for service
activation and potential service changes.
B64-3767-0000KEnglish.indd50B64-3767-0000KEnglish.indd50 07.5.102:16:05PM07.5.102:16:05PM

Kenwood eXcelon KDC-X991 Specifications

FM Tuner Section

frequency range	87.9 MHz – 107.9 MHz
usable sensitivity	9.3 dBf (0.8 μV/75 Ω)
quieting sensitivity	15.2 dBf (1.6 μV/75 Ω)
frequency response	30 Hz – 15 kHz
signal to noise ratio (MONO)	70 dB
selectivity	≥ 80 dB
stereo separation	40 dB

AM Tuner Section

frequency range	530 kHz – 1700 kHz
usable sensitivity	28 dBμ (25 μV)

CD Player Section

spindle speed	1000 – 400 rpm (CLV 2times)
frequency response	10 Hz – 20 kHz
total harmonic distortion	0.008 %
signal to noise ratio	110 dB
dynamic range	93 dB

USB Interface

usb standard	USB 1.1/ 2.0
maximum supply current	500 mA
file system	FAT16/ 32

Audio Section

maximum output power	50 W x 4
full bandwidth power	22 W x 4
speaker impedance	4 – 8 Ω
tone action band 1	60 – 200 Hz ±9 dB
tone action band 2	250 – 1k Hz ±9 dB
tone action band 3	1.25k – 4k Hz ±9 dB
tone action band 4	5k – 16k Hz ±9 dB
preout level / load	5000 mV/10 kΩ
preout impedance	≤ 80 Ω

Auxiliary Input

frequency response	20 Hz – 20 kHz
input maximum voltage	1200 mV
input impedance	100 kΩ

General

operating voltage	14.4 V
current consumption	10 A
installation size	182 x 53 x 155 mm
weight	3.31 lbs (1.5 kg)
