KETRON Audya - Page 157

MIDI Implementation
KETRON • AUDYA 157
MIDI Implementation
Effects NRPN
▀
NRPN
84H
NRPN
4H
Data MSB Default value Parameter
Compressor
100 00 0,1...127 0 Compressor switch:
0: Off
1...127: On
100 01 0...127 0 Attack time: 0=fast attack (0.1 ms), ... 60=1ms. .. . 100=
10ms, 127=slow attack (100ms), exp. curve
100 02 0...127 0 Release time: 0=fast release (10ms) , ...60= 100 ms, ...
100=1 s. 127=slow release (5s), exp. curve
100 03 0...127 0 Threshold: 127=0dB, 96=-6dB, 64=-12dB, 45=-18dB,
32=-24dB, 16=-36dB, 8=-48dB , 0=-64dB
100 04 0...127 48 Ratio: 127=1/128 (128:1), 126=2/128 (64:1), 125=3/128, ...
64=64/128 (2:1), ... 0=1:1
100 05 0...127 48 Boost (applied to signal after compression) :
127=x8, 64=x4,32=x2, 16 to 0=x1
100 06 0...7 0 Compressor preset: calls a compressor preset, i.e.
overwrites NRPN 100-01 t0 100-05 with predefined values.
See table below for description of the presets.
Lead EQ
101 32 40... 64...
76
64 Input gain: -24dB .. . 0dB ... +12dB (1 dB step)
101 0-9 50... 64...
78
64 Band gain: -14dB...0dB.. .+14dB (1 dB step)
Harmony EQ
102 32 40...64...76 64 Input gain: -24d B ... OdB .. . +12dB (1 dB step)
102 0-9 50...64...78 64 Band gain: -14dB...OdB.. .+14dB (1 dB step)
Reverb/Ech0
Reverb/Echo
103 00 0...127 0 Lead voice reverb send level: same as CC #5Bh on lead
channel
103 01 0...127 0 Harmony reverb send level: same as CC #5Bh on
harmony channel
103 02 0...127 127
Reverb level
103 03 0...127 127
Echo level
103 04 0...127 - Reverb time: 0=40ms
103 05 0...127 - Echo time: 0=40ms to 127=400ms
103 06 0...127 - Reverb/echo high pass lter on input: 0= no filter
103 07 0...127 - Reverb damp: high frequency filter on reverb decay
103 08 0...127 - Echo damp: high frequency filter echo feedback
103 09 0...127 -
Echo feedback
103 10 0...18 0 Reverb preset: calls a reverb preset. See table below for
description of the presets.
103 11 0...8 0 Echo preset: calls on echo preset. See table below for
description of the presets.
103 12 0...127 127
Reverb input level
103 13 0...127 0
Echo input level
103 14 0...127 0
Send echo to reverb
Note: EQ band frequencies are fixed to the following values:
