AUDIO connections
Stereo jack connection to a PA system.
Connecting 4 auxiliary outputs to a mixer and to a PA system.
AMPLIFIED SPEAKERS
AMPLIFIED SPEAKERS
MAIN OUT RIGHT/LEFT
AUX OUT 1, 2, 3 and 4
LINE INPUT 1 and 2
LINE INPUT 1, 2, 3 and 4
MAIN OUT L/R
MAIN OUT L/R
INPUT L
INPUT R
MIXER
MIXER
INPUT L
INPUT R
