B
C
3
After parameter “A” press “+”
to display “B”
After parameter “b” press “+”
to display “C”
Press “P”; the display shows
“2” to indicate that the built-in
courtesy light on the motor and
the external light COM-LED
are active
Press “P”; the display shows
“3” to indicate that the duration
of the courtesy light set in the
second radio channel is 3 min
Press “+” or “-” to select the required function:
0= only motor courtesy light active
1= only external courtesy light COM-LED active
2= motor courtesy light + external courtesy light COM-LED active
3= pedestrian function active: partial opening of 1 m
(Default setting: “2”)
(Default setting: "3”)
Note: in order to exit the programming and save the parameters push P button for 5 seconds.
Note: in order to exit the programming and save the parameters push P button for 5 seconds.
On each automation movement command, the courtesy led light on the motor, and external courtesy light COM+LED (if tted) will
remain lit for 3 minutes.
Value 0 1 2 3 4 5 6 7 8 9
Time not active 1 min 2 min 3 min 5 min 15 min 30 min 1 h 8 h 12 h
4.20 End of programming
Warning: this nal step must be done otherwise information will not be saved.
It is possible to abandon the programming phase and save data in any step on the functions menu from 4.11 to 4.20 in the following mode:
Press “P” in any function from 1
to 9 until the display shows the
set value
Press and hold “P” for 5 sec-
onds to save the modications
made
A beep followed by a sliding “0”
indicates that the programming
procedure has concluded suc-
cessfully
