2 Front-Panel Overview
74 Keysight 34970A/34972A User’s Guide
To Store the Instrument State
You can store the instrument state in one of five non-volatile storage locations. A
sixth storage location automatically holds the power-down configuration of the
instrument. When power is restored, the instrument can automatically return to its
state before power-down (a scan in progress before power-down will also be
resumed).
1 Select the storage location.
From the front panel, you have the ability to assign names (up to 12
characters) to each of the five stored states.
The storage locations are numbered 1 through 5. The power-down state is
automatically stored and can be recalled from the front panel (the state is
named LAST PWR DOWN).
2 Store the instrument state
The instrument stores all channel configurations, alarm values, scaling values,
scan interval setups, and advanced measurement configurations.
NAME STATE
1: TEST_RACK_2
STORE STATE
2: STATE2
CHANGE SAVED
