53220A/53230A Measurements 3
Keysight 53220A/53230A User’s Guide 119
Totalizing Measurements
The 53220A/53230A measurements covered in this section include gated and
continuous totalizing measurements.
Gated
Gated (timed) totalizing measurements count events (edges) that occur on the
channel over a specified period.
The relationship of the gate to the period input events are totalized is shown in
Figure 3-12.
The SCPI commands listed in these examples are provided as an introduction to
how totalizing measurements are made. Commands may be included even
though they specify default values - but which should be considered when
modifying the examples for actual use. Refer to the ‘Programmer’s Reference’ on
the Keysight 53210A/53220A/53230A Product Reference CD for additional
information.
