53220A/53230A Measurements 3
Keysight 53220A/53230A User’s Guide 89
The MEASure and CONFigure Commands
Each time the counter takes a measurement it does so from a configuration based
on multiple parameters. The easiest and most common starting point for setting
these parameters programmatically is using commands within the CONFigure
and MEASure subsystems. These commands are considered “high-level”
commands as multiple counter parameters are set or defaulted from a single
command. “Low-level” commands are those within other subsystems (i.e. INPut,
TRIGger, SENSe) that allow you to change a parameter value from that set, or
defaulted to, using CONFigure or MEASure.
Executing commands from the CONFigure and MEASure subsystems is equivalent
to setting parameters individually using the commands/subsystems shown in
Table 3-2.
Table 3-2 Counter configuration using CONFigure and MEASure
Parameter CONFigure/MEASure Setting Low-Level Command/Subsystem
Input
range, low-pass filtering, coupling, impedance
and noise rejection are unchanged from previous
or their power-on settings.
INPut{1|2}:RANGe
INPut{1|2}:FILTer
INPut{1|2}:COUPling
INPut{1|2}:IMPedance
INPut{1|2}:NREJect
Measurement Mode
AUTO for frequency, frequency ratio, average
period, PRF, or PRI measurements. Unchanged for
all others.
SENSe:FREQuency:MODE
Trigger source IMMediate TRIGger:SOURce
Trigger slope NEGative TRIGger:SLOPe
Trigger delay 0.0 seconds TRIGger:DELay
Trigger count 1 trigger TRIGger:COUNt
Sample count 1 sample SAMPle:COUNt
GATE Source
Based on measurement function specified by the
CONFigure or MEASure command.
SENSe:FREQuency:GATE:SOURce
SENSe:TINTerval:GATE:SOURce
SENSe:TOTalize:GATE:SOURce
GATE Start Source IMMediate SENSe:GATE:STARt:SOURce
GATE Start Slope NEGative SENSe:GATE:STARt:SLOPe
