Counter Measurement Summary
The Keysight 53220A and 53230A counter measurements are summarized in
Table 3-1. The table includes the front panel keys under which specific
measurements are selected via soft-keys. Also provided are the equivalent SCPI
commands and channel restrictions.
Table 3-1 Keysight 53220A/53230A Measurement Summary
Measurement Key Command Instrument Channels
Frequency
CONFigure:FREQuency
MEASure:FREQuency?
53220A/53230A 1,2,3
Frequency ratio
CONFigure:FREQuency:RATio
MEASure:FREQuency:RATio?
53220A/53230A 1,2,3
Period
CONFigure:PERiod
MEASure:PERiod?
53220A/53230A 1,2,3
SPeriod
CONFigure:SPERiod
MEASure:SPERiod?
53220A/53230A 1,2
Burst carrier frequency
CONFigure:FREQuency:BURSt
MEASure:FREQuency:BURSt?
53230A
3
(Opt. 150)
Pulse repetition frequency
CONFigure:FREQuency:PRF
MEASure:FREQuency:PRF?
53230A
3
(Opt. 150)
Pulse repetition interval
CONFigure:FREQuency:PRI
MEASure:FREQuency:PRI?
53230A
3
(Opt. 150)
Burst positive width
(“on time”)
CONFigure:PWIDth:BURSt
MEASure:PWIDth:BURSt?
53230A
3
(Opt. 150)
Burst negative width
(“off time”)
CONFigure:NWIDth:BURSt
MEASure:NWIDth:BURSt?
53230A
3
(Opt. 150)
Time interval
CONFigure:TINTerval
MEASure:TINTerval?
53220A/53230A 1,2
Rise time
CONFigure:RTIMe
MEASure:RTIMe?
53220A/53230A 1,2
Freq
Period
Freq
Period
Freq
Period
Freq
Period
Freq
Period
Freq
Period
Freq
Period
Freq
Period
Freq
Period
Time
Interval
Time
Interval
