Keysight 53230A - Figure 6-7 15-Bin (Point) Histogram; Histogram Configuration

53220A/53230A Math, Graphing, and Data Logging 6
Keysight 53220A/53230A User’s Guide 225
Histogram configuration
Histograms are configured using the softkeys and commands shown in
Figure 6-7.
Figure 6-7 15-bin (point) histogram.
Histogram computation is enabled with the command:
CALCulate2:TRANsform:HISTogram[:STATe] {OFF|ON}
CALCulate2:TRANsform:HISTogram[:STATe]? (query form)
ON - enables histogram computation.
OFF - disables histogram computation. Following a reset (*RST), instrument
preset (SYSTem:PRESet), or front panel (Preset) histograms are disabled.
CALCulate2:TRANsform:HISTogram:STATe ON
CALCulate2:TRANsform:HISTogram:RANGe:LOWer
CALCulate2:TRANsform:HISTogram:RANGe:UPPer
CALCulate2:TRANsform:HISTogram:POINts
CALCulate2:TRANsform:HISTogram:RANGe:AUTO
CALCulate2:TRANsform:HISTogram:RANGe:AUTO:COUNt
CALCulate2:TRANsform:HISTogram:CLEar
CALCulate2:TRANsform:HISTogram:COUNt?
