6 53220A/53230A Math, Graphing, and Data Logging
214 Keysight 53220A/53230A User’s Guide
CALC:SCAL:UNIT "sec" // assign units to readings
INIT // initiate readings
For an input frequency of 1 MHz, the counter should display readings of
approximately +100.00... usec.
Statistics
Statistical calculations are performed continually on readings as they are taken, or
until the total reading count (TRIGger:COUNt x SAMPle:COUNt) is reached. The
commands used to generate statistical data are covered in this section.
As mentioned, multiple operations can be enabled at the same time. Figure 6-3 is
an example with statistics and limit checking enabled.
Figure 6-3 Counter display with limit testing and statistics enabled.
CALCulate1:AVERage:STATe ON
CALCulate1:STATe ON
CALCulate1:AVERage CLEar
