Keysight 53230A - Figure 6-2 53220 A;53230 A Display with Scaling Functions Enabled

6 53220A/53230A Math, Graphing, and Data Logging
208 Keysight 53220A/53230A User’s Guide
Figure 6-2 53220A/53230A display with scaling functions enabled.
Enabling the scale functions
All 53220A/53230A scaling functions are enabled with the command:
CALCulate[1]:SCALe[:STATe] {OFF|ON}
CALCulate[1]:SCALe[:STATe]? (query form)
ON enables scaling. OFF disables scaling.
Following a reset (*RST) or instrument preset (SYSTem:PRESet), scaling is
disabled.
CALCulate1:SCALe:UNIT
CALCulate1:SCALe:UNIT:STATe ON
CALCulate1:SCALe:STATe ON
CALCulate1:STATe ON
CALCulate1:SCALe:FUNCtion
