102 Keysight E5092A ENA Series Configurable Multiport Test Set
Performance Tests
E5092A Performance Test Record
2-
Load Match, Insertion Loss and Isolation Test for Switch 4(SP4T, Port 4, 4A, 4B,
4C and 4D)
Load Match (Unselected)
Port
(Selected
Port)
Frequency
Range [Hz]
Test Limit
[dB]
Test Result [dB] Measurement
Uncertainty [dB]
4B (4A) 50M to 3G < -17.0  0.43
3G to 10G < -11.0  0.37
10G to 16G < -8.0  0.28
16G to 18G < -6.0  0.28
18G to 20G < -4.0  0.35
4C (4A) 50M to 3G < -17.0  0.43
3G to 10G < -11.0  0.37
10G to 16G < -8.0  0.28
16G to 18G < -6.0  0.28
18G to 20G < -4.0  0.35
4D (4A) 50M to 3G < -17.0  0.43
3G to 10G < -11.0  0.37
10G to 16G < -8.0  0.28
16G to 18G < -6.0  0.28
18G to 20G < -4.0  0.35
4A (4B) 50M to 3G < -17.0  0.43
3G to 10G < -11.0  0.37
10G to 16G < -8.0  0.28
16G to 18G < -6.0  0.28
18G to 20G < -4.0  0.35
4C (4B) 50M to 3G < -17.0  0.43
3G to 10G < -11.0  0.37
10G to 16G < -8.0  0.28
16G to 18G < -6.0  0.28
18G to 20G < -4.0  0.35
