Keysight E5092A ENA Series Configurable Multiport Test Set 25
Performance Tests
5. LOAD MATCH, INSERTION LOSS, ISOLATION for SWITCH 3 (SP4T, PORT 3, 3A, 3B,
3C and 3D)
5. LOAD MATCH, INSERTION LOSS, ISOLATION for SWITCH 3 (SP4T,
PORT 3, 3A, 3B, 3C and 3D)
Description
This test checks the Load Match, Insertion loss and Isolation for ports 3A, 3B,
3C and 3D of the E5092A. These parameters checked at 50 MHz through 20
GHz with the N5230A Network Analyzer.
Specification
@ 23 °C  5 °C (Warming up over 90 minutes)
Load Match (Selected port)
Load Match (Unselected port)
Load Match (Common port)
SP4T Switch Specification
50 MHz to 2 GHz 17 dB
2 GHz to 4 GHz 11 dB
4 GHz to 8 GHz 8 dB
8 GHz to 10 GHz 7 dB
10 GHz to 18 GHz 4 dB
18 GHz to 20 GHz 4 dB
SP4T Switch Specification
50 MHz to 3 GHz 17 dB
3 GHz to 10 GHz 11 dB
10 GHz to 16 GHz 8 dB
16 GHz to 18 GHz 6 dB
18 GHz to 20 GHz 4 dB
SP4T Switch Specification
50 MHz to 2 GHz 16 dB
2 GHz to 4 GHz 11 dB
4 GHz to 8 GHz 8 dB
8 GHz to 10 GHz 7 dB
