188 Keysight E5092A ENA Series Configurable Multiport Test Set
Replacement Procedure
Required Tools
5-
Required Tools
The following tools are required for repair of E5092A-020.
Table 5-1 Required Tools for E5092A-020
Assembly TORX Screwdriver Box
wrench
Open
wrench
T
10
T
15
T
20
T
25
5.5mm 5/8 in.
Outer Cover √√√
Front chassis √√√
Front Frame √√√
A1 Switch Control
Board
√√√
Power Supply √√√
Power Switch √√√
Main Board √√√ √
SP4T Switch √√√ √ √
SP4T Raptor Holder √√√ √ √
SPDT Switch Drawer √√√ √ √
SPDT Switch √√√ √ √
Switch Indicator LED √√√ √
