Keysight E5092A ENA Series Configurable Multiport Test Set 151
Troubleshooting
E5092A Setting Troubleshooting
Step 7. Use the corresponding softkey to assign between the test ports of the
E5092A and the interconnection ports.
Step 8. Check that the LEDs on the Port Connection Indicator are the same ports as
the E5092A property display.
• If any of the ports setting are different from the E5092A property display,
the A1 board is suspect.
• If all the ports are good, the A1 board is verified.
Check the temperature control
Step 1. Connect the USB cable furnished with E5092A between the rear panel of the
E5071C and that of the E5092A.
Step 2. Turn on the E5071C and the E5092A. Allow them to warm up for at least 30
minutes before you proceed the next step.
Step 3. Press - Service Menu - Service Functions. Then password dialog box
will appear. Enter the password kid in the password box and then click OK
button.
Step 4. Press E5092A Service Functions - E5092A ID(1).
Softkey Function
Port1 Selects a test port of the E5092A to
which you want to connect port 1 of the
E5092A. You can select the port from A,
T1, T2 or T3.
Port2 Selects a test port of the E5092A to
which you want to connect port 2 of the
E5092A. You can select the port from T1,
T2, T3 or T4.
Port3 Selects a test port of the E5092A to
which you want to connect port 3 of the
E5092A. You can select the port from
R1+, R2+, R3+ or R4+
Port4 Selects a test port of the E5092A to
which you want to connect port 4 of the
E5092A. You can select the port from
R1-, R2-, R3- or R4-.
