46 Keysight E5092A ENA Series Configurable Multiport Test Set
Performance Tests
12. LOAD MATCH, INSERTION LOSS, ISOLATION for SWITCH 10 (SPDT, PORT 10, 10A
and 10B)
2-
12. LOAD MATCH, INSERTION LOSS, ISOLATION for SWITCH 10 (SPDT,
PORT 10, 10A and 10B)
Description
This test checks the Load Match, Insertion Loss and Isolation for ports 10COM,
10A and 10B of the E5092A. These parameters checked at 50 MHz through 20
GHz with the N5230A Network Analyzer.
Specification
@ 23 °C  5 °C (Warming up over 90 minutes)
Load Match (Selected port)
Load Match (Unselected port)
Load Match (Common port)
SPDT Switch Specification
50 MHz to 2 GHz 17 dB
2 GHz to 4 GHz 11 dB
4 GHz to 8 GHz 8 dB
8 GHz to 10 GHz 7 dB
10 GHz to 18 GHz 4 dB
18 GHz to 20 GHz 4 dB
SPDT Switch Specification
50 MHz to 3 GHz 17 dB
3 GHz to 10 GHz 11 dB
10 GHz to 16 GHz 8 dB
16 GHz to 18 GHz 6 dB
18 GHz to 20 GHz 4 dB
SPDT Switch Specification
50 MHz to 2 GHz 16 dB
2 GHz to 4 GHz 11 dB
4 GHz to 8 GHz 8 dB
8 GHz to 10 GHz 7 dB
