184 Keysight E5092A ENA Series Configurable Multiport Test Set

Replaceable Parts

Replaceable Parts List for E5092A-020

LED Assembly

Figure 4-22 LED Assembly

Table 4-22 LED Assembly

Ref.

Desig.

Keysight Part Number Qty. Description

1 E5092-66602 1 SW INDICATOR LED PCA

2 0515-0430 2 SCREW MACH M3X0.5
