Keysight E5092A ENA Series Configurable Multiport Test Set 169

Replaceable Parts

Replaceable Parts List for E5092A-020

Bottom View (Cables)

Figure 4-9 Bottom View (Cables)

Table 4-9 Bottom View (Cables)

Ref.

Desig.

Keysight Part Number Qty. Description

1 E5092-61646 1 WIRE ASSY

2 E5092-61667 2 CABLE ASSY THERMOSENSOR
