Keysight E5092A ENA Series Configurable Multiport Test Set 17
Performance Tests
1. DC SOURCE OUTPUT VOLTAGE ACCURACY TEST
1. DC SOURCE OUTPUT VOLTAGE ACCURACY TEST
Description
This test measures the DC source output voltage for each control line.
Specification
@ 23 °C 5 °C (Warming up over 90 minutes)
3% of setting (+ 1V to 5V) at 1M load impedance.
Test equipment
DC Power Supply Keysight E3631A
Digital Multimeter Keysight 34410A
Multifunction Switch/Measure Unit Keysight 34980A
40-Channel Armature Multiplexer for 34980A Keysight 34921A
ET Keysight E5092-66590
