Keysight ENA Series User Manual

24 Keysight E5092A ENA Series Configurable Multiport Test Set
Performance Tests
4. LOAD MATCH, INSERTION LOSS, ISOLATION TEST for SWITCH 2 (SP4T, PORT 2, 2A,
2B, 2C and 2D)
2-
Test equipment
Network Analyzer Keysight N5230A Opt. 240 or 245
DC Power Supply Keysight E3631A
Digital Multimeter Keysight 34410A
Multifunction Switch/Measure Unit Keysight 34980A
40-Channel Armature Multiplexer for 34980A Keysight 34921A
ET Keysight E5092-66590

Keysight ENA Series Specifications

General

Number of Ports	2 or 4
Dynamic Range	> 123 dB (typical)
Interface	LAN, USB, GPIB
Frequency Range	9 kHz to 8.5 GHz
Trace Noise	0.004 dB rms
IF Bandwidth	1 Hz to 3 MHz
Impedance	50 Ohm
Connector Type	Type-N
Display	LCD
