Keysight E5092A ENA Series Configurable Multiport Test Set 23
Performance Tests
4. LOAD MATCH, INSERTION LOSS, ISOLATION TEST for SWITCH 2 (SP4T, PORT 2, 2A,
2B, 2C and 2D)
Insertion Loss
Isolation
10 GHz to 20 GHz 4 dB
SP4T Switch Specification
50 MHz to 100 MHz 4 dB
100 MHz to 2 GHz 3.5 dB
2 GHz to 3 GHz 4.5 dB
3 GHz to 4GHz 5.5 dB
4 GHz to 6 GHz 6 dB
6 GHz to 8GHz 7.5 dB
8 GHz to 10 GHz 8.5 dB
10 GHz to 14GHz 9.5 dB
14 GHz to 18 GHz 10.5 dB
18 GHz to 20 GHz 12 dB
Frequency Specification
50 MHz to 500 MHz 65 dB
500 MHz to 1 GHz 80 dB
1 GHz to 2 GHz 85 dB
2 GHz to 6 GHz 90 dB
6 GHz to 10 GHz 85 dB
8 GHz to 10 GHz 75 dB
10 GHz to 18GHz 65 dB
18 GHz to 20 GHz Over arbitary test ports
