Keysight E5092A ENA Series Configurable Multiport Test Set 139
Performance Tests
E5092A Performance Test Record
Load Match, Insertion Loss and Isolation Test for Switch 10(SPDT, 10COM, 10A
and 10B)
Load Match (Unselected)
Load Match (Selected)
Port
(Selected
Port)
Frequency
Range [Hz]
Test Limit
[dB]
Test Result [dB] Measurement
Uncertainty
[dB]
10A (10B) 50M to 3G < -17.0  0.43
3G to 10G < -11.0  0.37
10G to 16G < -8.0  0.28
16G to 18G < -6.0  0.28
18G to 20G < -4.0  0.35
Port
(Selected
Port)
Frequency
Range [Hz]
Test Limit
[dB]
Test Result [dB] Measurement
Uncertainty [dB]
10A (10A) 50M to 2G < -17.0  0.37
2G to 4G < -11.0  0.27
4G to 8G < -8.0  0.18
8G to 10G < -7.0  0.28
10G to 18G < -4.0  0.29
18G to 20G < -4.0  0.29
10B (10B) 50M to 2G < -17.0  0.37
2G to 4G < -11.0  0.27
4G to 8G < -8.0  0.18
8G to 10G < -7.0  0.28
10G to 18G < -4.0  0.29
18G to 20G < -4.0  0.29
