Keysight ENA Series

140 Keysight E5092A ENA Series Configurable Multiport Test Set
Performance Tests
E5092A Performance Test Record
2-
Load Match (COM)
Insertion Loss
Port
(Selected
Port)
Frequency
Range [Hz]
Test Limit
[dB]
Test Result [dB] Measurement
Uncertainty [dB]
10COM
(10A)
50M to 2G < -16.0  0.30
2G to 4G < -11.0  0.23
4G to 8G < -8.0  0.12
8G to 10G < -7.0  0.13
10G to 20G < -4.0  0.10
10COM
(10B)
50M to 2G < -16.0  0.30
2G to 4G < -11.0  0.23
4G to 8G < -8.0  0.12
8G to 10G < -7.0  0.13
10G to 20G < -4.0  0.10
From Port -
To Port
Frequency
Range [Hz]
Test Limit
[dB]
Test Result [dB] Measurement
Uncertainty [dB]
10COM -
10A
50M to 100M > -4.0  0.27
100M to 2G > -3.5  0.24
2G to 3G > -4.5  0.18
3G to 4G > -5.0  0.19
4G to 6G > -5.5  0.11
6G to 8G > -7.0  0.09
8G to 10G > -8.0  0.24
10G to 14G > -8.5  0.23
14G to 18G > -10.0  0.29
18G to 20G > -11.5  0.59
