Keysight ENA Series

Keysight E5092A ENA Series Configurable Multiport Test Set 141
Performance Tests
E5092A Performance Test Record
Isolation
From Common Port to Unselected Port
10COM -
10B
50M to 100M > -4.0  0.27
100M to 2G > -3.5  0.24
2G to 3G > -4.5  0.18
3G to 4G > -5.0  0.19
4G to 6G > -5.5  0.11
6G to 8G > -7.0  0.09
8G to 10G > -8.0  0.24
10G to 14G > -8.5  0.23
14G to 18G > -10.0  0.29
18G to 20G > -11.5  0.59
From Port -
To Port
(Selected
Port)
Frequency
Range [Hz]
Test Limit
[dB]
Test Result [dB] Measurement
Uncertainty [dB]
10COM -
10A (10B)
50M to 500M < -65.0  0.35
500M to 1G < -80.0  0.48
1G to 2G < -85.0  0.60
2G to 6G < -90.0  0.76
6G to 10G < -85.0  0.66
10G to 18G < -75.0  0.54
18G to 20G < -65.0  0.43
From Port -
To Port
Frequency
Range [Hz]
Test Limit
[dB]
Test Result [dB] Measurement
Uncertainty [dB]
