Keysight ENA Series - Required Equipment

Keysight E5092A ENA Series Configurable Multiport Test Set 13
General Information
Required Equipment
Required Equipment
Table 1-1 lists the recommended equipment for performing maintenance on
the E5092A.
Table 1-1 Recommended Test Equipment
Equipment Critical specifications Recommended Model Qty.
Use
1
Network Analyzer Frequency: 200 kHz to 20 GHz Keysight N5230A 1 P
Multifunction Switch Keysight 34980A 1 P
Multiplexer 40-channel Armature Multiplexer
for 34980A
Keysight 34921A 1 P
Digital I/O 64-bit Digital I/O with memory and
counter for 34980A
Keysight 34950A 1 P
Multimeter Keysight 3458A 1 P
DC Power Supply Programmable Triple Output Keysight E3631A 1 P
ET ET for DUT Control Line Test Keysight E5092-66590 1 P
Load 50 , DC to 26.5GHz(m) Keysight p/n 00902-60003 1 P
Cable BNC Cable, 120cm
BNC(f) - Dual Banana(m)
Keysight p/n 8120-1840
Keysight p/n 1251-2277
3
3
P, A
Cable D-SUB 50pin (f)-(f)
D-SUB 78pin (m)-(m)
D-SUB 15pin (m)-(m)
D-SUB 25pin (m)-(m)
Keysight p/n 5188-4493
Keysight p/n 5188-4494
Keysight p/n 5188-4491
Keysight p/n 5188-4492
2
1
1
1
P
Cable 3.5mm Cable, 1m 4 P
Cable GPIB Cable Keysight 10833A 4 P
Cable USB Cable USB2-30 1 P
Adapter SMB(m)-BNC(f) Adapter Keysight p/n 1250-3938 1 P
Adapter BNC T Adapter (f)-(m)-(f) Keysight p/n 1250-0781 1 P
Torque Wrench Keysight p/n 8710-1766 1 P
1. P: Performance Tests, A: Adjustment Tests
