104 Keysight E5092A ENA Series Configurable Multiport Test Set
Performance Tests
E5092A Performance Test Record
2-
Load Match (Selected)
4B (4D) 50M to 3G < -17.0  0.43
3G to 10G < -11.0  0.37
10G to 16G < -8.0  0.28
16G to 18G < -6.0  0.28
18G to 20G < -4.0  0.35
4C (4D) 50M to 3G < -17.0  0.43
3G to 10G < -11.0  0.37
10G to 16G < -8.0  0.28
16G to 18G < -6.0  0.28
18G to 20G < -4.0  0.35
Port (Selected
Port)
Frequency
Range [Hz]
Test Limit
[dB]
Test Result [dB] Measurement
Uncertainty [dB]
4A (4A) 50M to 2G < -17.0  0.37
2G to 3G < -11.0  0.28
3G to 8G < -8.0  0.18
8G to 10G < -7.0  0.28
10G to 18G < -4.0  0.29
18G to 20G < -4.0  0.29
4B (4B) 50M to 2G < -17.0  0.37
2G to 3G < -11.0  0.28
3G to 8G < -8.0  0.18
8G to 10G < -7.0  0.28
10G to 18G < -4.0  0.29
18G to 20G < -4.0  0.29
Port
(Selected
Port)
Frequency
Range [Hz]
Test Limit
[dB]
Test Result [dB] Measurement
Uncertainty [dB]
