Keysight E5092A ENA Series Configurable Multiport Test Set 127
Performance Tests
E5092A Performance Test Record
Load Match, Insertion Loss and Isolation Test for Switch 7 (SPDT, 7COM, 7A and
7B)
Load Match (Unselected)
Load Match (Selected)
Port
(Selected
Port)
Frequency
Range [Hz]
Test Limit
[dB]
Test Result [dB] Measurement
Uncertainty
[dB]
7A (7B) 50M to 3G < -17.0  0.43
3G to 10G < -11.0  0.37
10G to 16G < -8.0  0.28
16G to 18G < -6.0  0.28
18G to 20G < -4.0  0.35
Port
(Selected
Port)
Frequency
Range [Hz]
Test Limit
[dB]
Test Result [dB] Measurement
Uncertainty [dB]
7A (7A) 50M to 2G < -17.0  0.37
2G to 4G < -11.0  0.27
4G to 8G < -8.0  0.18
8G to 10G < -7.0  0.28
10G to 18G < -4.0  0.29
18G to 20G < -4.0  0.29
7B (7B) 50M to 2G < -17.0  0.37
2G to 4G < -11.0  0.27
4G to 8G < -8.0  0.18
8G to 10G < -7.0  0.28
10G to 18G < -4.0  0.29
18G to 20G < -4.0  0.29
