Keysight ENA Series

68 Keysight E5092A ENA Series Configurable Multiport Test Set
Performance Tests
E5092A Performance Test Record
2-
Load Match, Insertion Loss and Isolation Test for Switch 2(SP4T, Port 2, 2A, 2B,
2C and 2D)
Load Match (Unselected)
Port
(Selected
Port)
Frequency
Range [Hz]
Test Limit
[dB]
Test Result [dB] Measurement
Uncertainty [dB]
2B (2A) 50M to 3G < -17.0  0.43
3G to 10G < -11.0  0.37
10G to 16G < -8.0  0.28
16G to 18G < -6.0  0.28
18G to 20G < -4.0  0.35
2C (2A) 50M to 3G < -17.0  0.43
3G to 10G < -11.0  0.37
10G to 16G < -8.0  0.28
16G to 18G < -6.0  0.28
18G to 20G < -4.0  0.35
2D (2A) 50M to 3G < -17.0  0.43
3G to 10G < -11.0  0.37
10G to 16G < -8.0  0.28
16G to 18G < -6.0  0.28
18G to 20G < -4.0  0.35
2A (2B) 50M to 3G < -17.0  0.43
3G to 10G < -11.0  0.37
10G to 16G < -8.0  0.28
16G to 18G < -6.0  0.28
18G to 20G < -4.0  0.35
2C (2B) 50M to 3G < -17.0  0.43
3G to 10G < -11.0  0.37
10G to 16G < -8.0  0.28
16G to 18G < -6.0  0.28
18G to 20G < -4.0  0.35
