Kia Cerato 2021 - Page 634

Maintenance
808
Fuses
MODULE3 7.5A Sport Mode Switch, Stop Lamp Switch
A/C2 10A
Engine Room Junction Block (BLOWER Relay), Air
Conditioner Control Module, Blower Resistor, Blower
Motor, ECM (Engine Control Module)/PCM (Power
train Control Module)
START 7.5A
Transaxle Range Switch, Engine Room Junction Block
(PDM 3 (IG1) Relay), IBU (Integrated Body Control
Unit), ECM (Engine Control Module), PCM (Power train
Control Module), Position switch
MODULE 2 10A
Audio, Audio/Video & Navigation Head Unit, IBU (Inte
-
grated Body Control Unit), MTS (Mozen Telematics
System) E-Call Module, Rear USB Charger, Wireless
Charger, EPB switch
Fuse
Name
Symbol
Fuse
rating
Circuit Protected
