Maintenance Fuses
MODULE 1 10A
Key Interlock Switch, Multipurpose Check Connector,
Data Link Connector, ICM (Integrated Circuit Module)
Relay Box (Outside Mirror Folding/Unfolding Relay),
Hazard Switch, Driver/Passenger Smart Key Outside
Handle, Mood Lamp Control Unit
TRUNK 10A Trunk Relay
S/HEATER
FRT
20A
Front Seat Warmer Control Module, Front Air Ventila
-
tion Seat Control Module
MDPS 7.5A MDPS (Motor Driven Power Steering) Unit
MODULE4 7.5A
Lane Keeping Assist Unit, IBU (Integrated Body Con
-
trol Unit), Forward Collision Avoidance Assist Unit,
EPB switch
MODULE 5 10A
MTS (Mozen Telematics System) E-Call Module,
Crash Pad Switch, Electro Chromic Mirror, Audio/
Video & Navigation Head Unit, Audio, Air Conditioner
Control Module, Rear Seat Warmer Control Module,
Front Seat Warmer Control Module, Front Air Ventila
-
tion Seat Control Module, Driver IMS (Integrated
memory system) Module, Head Lamp Left Handle
side/Right Handle side, Auto Transmission Shift Lever
Indicator, Multipurpose Check Connector, Data Link
Connector
AIR BAG2 10A SRS (Supplemental Restraint System) Control Module
BRAKE
SWITCH
10A IBU (Integrated Body Control Unit), Stop Lamp Switch
AIR BAG
IND
7.5A Instrument Cluster, Air Conditioner Control Module
IG1 25A
Engine Room Junction Block (Fuse - ABS3, ECU5,
TCU2, SENEOR4)
IBU1 15A IBU (Integrated Body Control Unit)
CLUSTER 7.5A Instrument Cluster
IBU2 7.5A IBU (Integrated Body Control Unit)
WIPER 10A
Engine Room Junction Block (Front Wiper (Low)
Relay), Front Wiper Motor, ECM (Engine Control Mod
-
ule)/PCM (Power train Control Module), IBU (Inter
grated Body Control Unit)
Fuse
Name
Symbol
Fuse
rating
Circuit Protected
