Chapter 3: System operation
P/N 3102351-EN • REV 005 • ISS 28DEC18 137
Table 41: Functions available for programmable buttons (Key #1 and Key #2)
Description
The first press turns on outputs in any number of correlation groups. The button LED turns
on.
The second press turns off these same outputs and the button LED.
The first press disables any number of correlation groups, correlation group members, or
both. The button LED turns on.
The second press enables the same set of correlation groups and correlation group
members and turns off the button LED.
The Disable function operates differently based on the whether you choose Correlation
Groups, Members of Correlation Group, or Both. The default value is Members.
• If you choose Disable Correlation Group:
An LCD message indicates that Corr Grp xxx is disabled
All outputs (including relay and sounder bases) are turned off and the disabled
correlation group stops operating
Note: Detector bases that are configured to be activated by their attached detector
cannot be disabled through group disable operation.
• If you choose Members of Correlation Group:
An LCD message identifies the Disabled members.
Disabling members of a correlation group does not disable relay or sounder bases.
Active devices cannot be enabled through a programmable button. To enable these
devices, press the Menu button and choose Control>Enable Device.
• If you choose Both:
The correlation group stops operating and all members are disabled.
An LCD message identifies the Disabled members.
Unlatches all latched outputs system-wide.
Restores outputs in any number of correlation groups to their normal state. (Disabled or
latched devices must be enabled or unlatched before they can be restored.)
Removes any function associated with the button.
Used for manual evacuation in the Canadian Marketplace. Pressing the Alarm ON button
places the control panel in the alarm condition, activates all drillable outputs which include all
notification appliance circuits and all sounder bases,
signals the central station with CID 115.
The panel still responds to initiating device circuits that are activated while sounding a
manual evacuation. The Alarm ON event is restored upon panel reset. If Alarm ON is
initiated while reset is in progress, the event will be restored at the end of reset.
To meet CAN/ULC-S527requirements, User Key 1 default is Alarm ON when the Canadian
marketplace is selected.
Programmable button function priority
• Operations such as Signal Silence, Auto Signal Silence, and Drill take priority over Activate,
Restore, and Disable.
