AUTOMATION AND CONTROL SYSTEM FOR UNITS EVO-T; EVO-T COMPACT
OPERATION AND MAINTENANCE MANUAL
Alarms
Alarm
type
System response, action / Alarms list
A_Trec Blocking
Inspection of air exhaust temperature sensor operation
downstream the heat recovery:
Normal condition – no alarm, sensor connected
Alarm condition – alarm triggered, sensor disconnected or faulty
Response to the alarm condition: the system is stopped, check
the sensor and its connection to the ELP11R19L BAC+ controller,
determine the problem source, once the alarm source is eliminated
the alarm is reset automatically and the system resumes operation
Sensor input PT4
A_
Tsup-
Prim
Blocking
Inspection of air supply temperature sensor operation
downstream the preliminary heater (if active in ‚Service/Se-
tup/Preliminary heater/Operation permit – active’ menu):
Normal condition – no alarm, sensor connected
Alarm condition – alarm triggered, sensor disconnected or faulty
Response to the alarm condition: the system is stopped, check
the sensor and its connection to the ELP11R19L BAC+ controller,
determine the problem source, once the alarm source is eliminated
the alarm is reset automatically and the system resumes operation
Sensor input PT5
A_
Tbac-
kWater
Fading
Inspection of correct operation of the heater’s return water
temperature sensor:
Normal condition – no alarm, sensor connected
Alarm condition – alarm triggered, sensor disconnected or faulty
Response to the alarm condition: the system is stopped, check the
sensor and its connection to the controller, determine the problem
source, once the alarm source is eliminated, conrm the alarm and
start the system
Sensor input PT5
A_
Tmain
Blocking
Master temperature sensor operation inspection:
Normal condition – no alarm, sensor connected
Alarm condition – alarm triggered, sensor disconnected or faulty
Response to the alarm condition: the system is stopped, check the
sensor and its connection to the ELP11R19L BAC+ controller, deter-
mine the problem source, once the alarm source is eliminated the
alarm is reset automatically and the system resumes operation
The input depends on the master sensor selection
Misc Alarms
A_Com-
SupFC
Fading
Communication inspection of the controller and air sup-
ply fan inverter or EC motor controller:
Normal condition – no alarm, correct communication
Alarm condition – alarm triggered, incorrect communication
Response to the alarm condition: the system is stopped, check
the inverter and its connection to the ELP11R19L BAC+ control-
ler or air supply EC motor controller, nd out the problem source,
once the problem is eliminated the system resumes operation
automatically.
A_Com-
SupFC2
Fading
Communication inspection of the controller and air sup-
ply fan secondary inverter or EC motor controller:
Normal condition – no alarm, correct communication
Alarm condition – alarm triggered, incorrect communication
Response to the alarm condition: the system is stopped, check
the inverter and its connection to the EELP11R19L BAC+ control-
ler or air supply EC motor controller, nd out the problem source,
once the problem is eliminated the system resumes operation
automatically.
A_Co-
mExhFC
Fading
Communication inspection of the controller and air
exhaust fan inverter or EC motor controller:
Normal condition – no alarm, correct communication
Alarm condition – alarm triggered, incorrect communication
Response to the alarm condition: the system is stopped, check
the inverter and its connection to the ELP11R19L BAC+ con-
troller or air exhaust EC motor controller, nd out the problem
source, once the problem is eliminated the system resumes
operation automatically.
A_Co-
mExhFC2
Fading
Communication inspection of the controller and air
exhaust fan secondary inverter or EC motor controller:
Normal condition – no alarm, correct communication
Alarm condition – alarm triggered, incorrect communication
Response to the alarm condition: the system is stopped, check
the inverter and its connection to the ELP11R19L BAC+ con-
troller or air exhaust EC motor controller, nd out the problem
source, once the problem is eliminated the system resumes
operation automatically.
A_Lo-
wTemp
Blocking
Inspecting suciently high air supply temperature:
Normal condition – no alarm, air supply temperature is maintained
above the min level
Alarm condition – alarm triggered, air supply temperature below
preset level within dened time
Response to the alarm condition: the system is stopped, check the heat
exchangers and system operation, once the problem is eliminated
conrm the alarm and start the system.
A_Col-
dRec
Fading
Frosting inspection of heat recovery air exhaust part using
the temperature sensor:
Normal condition – no frosting, temperature high enough
Alarm condition – frosting present, temperature too low
Response to the alarm condition: the system operates, heat recovery
actuation is reduced, once the alarm disappears the system operates
with heat recovery if temperature adjustment is required, if the alarm
does not disappear for a longer time, check the heat recovery system
and revert it to the condition before the alarm occurred.
Sensor input PT4
Normal condition – no frosting, pressure dierence downstream and
upstream the heat recovery is lower than the one set on the pressure
gauge, no 24VAC signal at digital input
Alarm condition – frosting present, pressure dierence downstream
and upstream the heat recovery is higher than the one set on the
pressure gauge, 24VAC signal at digital input
Response to the alarm condition: the system operates, heat recovery
actuation is reduced, once the alarm disappears the system operates
with heat recovery if temperature adjustment is required, if the alarm
does not disappear for a longer time, check the heat recovery system
and revert it to the condition before the alarm occurred.
