AUTOMATION AND CONTROL SYSTEM FOR UNITS EVO-T; EVO-T COMPACT
OPERATION AND MAINTENANCE MANUAL
DEC address
Variable
name
Description / Variables Service Menu States
Type Read [R]
/Write
[W]
BacNet Modbus BacNet Modbus
257 514 Em_Hrs Emulation of input of sensor in setter connected to RS485 connector 0 – inactive, 1 – active MSV
Coil 8224
R/W
258 516 E_Hrs Emulated value of sensor in setter connected to RS485 connector 1°C=256(22°C = 22*256 = 5632 = 0x1600) AV Register R/W
259 518 F_Re1 Forcing of digital output 1
0 – no forcing, 1 – forcing deactivation,
3 – forcing activation
MSV Register R/W
260 520 F_Re2 Forcing of digital output 2
0 – no forcing, 1 – forcing deactivation,
3 – forcing activation
MSV Register R/W
261 522 F_Re3 Forcing of digital output 3
0 – no forcing, 1 – forcing deactivation,
3 – forcing activation
MSV Register R/W
262 524 F_Re4 Forcing of digital output 4
0 – no forcing, 1 – forcing deactivation,
3 – forcing activation
MSV Register R/W
263 526 F_Re5 Forcing of digital output 5
0 – no forcing, 1 – forcing deactivation,
3 – forcing activation
MSV Register R/W
264 528 F_Re6 Forcing of digital output 6
0 – no forcing, 1 – forcing deactivation,
3 – forcing activation
MSV Register R/W
265 530 FoAO1 Forcing of analogue output 1 0 – inactive, 1 – active MSV
Coil 8480
R/W
266 532 F_AO1 Value in the forcing mode for analogue output 1 1V = 256 (10V = 10*256 = 2560 = 0xA00) AV Register R/W
267 534 FoAO2 Forcing of analogue output 2 0 – inactive, 1 – active MSV
Coil 8544
R/W
268 536 F_AO2 Value in the forcing mode for analogue output 2 1V = 256 (10V = 10*256 = 2560 = 0xA00) AV Register R/W
269 538 FoAO3 Forcing of analogue output 3 0 – inactive, 1 – active MSV
Coil 8608
R/W
270 540 F_AO3 Value in the forcing mode for analogue output 3 1V = 256 (10V = 10*256 = 2560 = 0xA00) AV Register R/W
271 542
Device address
Device address 1 = 256 (10 = 10*256 = 2560 = 0xA00) AV Register Register
272 544 DCS Com.speed
0 – 2k4; 1 – 4k8; 2 – 9k6; 3 – 14k4; 4 – 19k2;
5 – 28k8; 6 – 38k4; 7 – 57k6; 8 – 76k8; 9 – 115k2
AV Register R/W
273 546 DCP Parity 0 – none, 1 – even, 2 – odd AV Register R/W
274 548 DCSt Stop bits 0 – 1 stop bit, 1 – 2 stop bits AV Register R/W
275 550 ADDR Variable address [DEC] 1 = 256 (10 = 10*256 = 2560 = 0xA00) AV Register R/W
276 552
Read_RS485
Read Modbus
0 – inactive, 1 – dig coil 1, 2 – dig coil 4,
4 – dig coil 8, 8 – dig input 1, 16 – dig input 4,
32 – dig input 8, 64 – register 1, 128 – register
4, 256 – register 8, 512 – input reg 1,
1024 – input reg 4, 2048 – input reg 8
AV Register R/W
277 554 PLread Read packets lost 1% = 256 (10% = 10*256 = 2560 = 0xA00) AV Register R
278 556 DigReaded Read Digital 1 = 256 (10 = 10*256 = 2560 = 0xA00) AV Register R
279 558 AnRead Read Analog 1 = 256 (10 = 10*256 = 2560 = 0xA00) AV Register R
280 560
Write_
RS485_activ
Write Modbus
0 – inactive, 1 – dig coil 1, 2 – dig coil 4,
4 – dig coil 8, 8 – register 1, 16 – register 4,
32 – register 8
AV Register R/W
281 562 PLwrite Write packets lost 1% = 256 (10% = 10*256 = 2560 = 0xA00) AV Register R
282 564 SetDigital Write Digital 1 = 256 (10 = 10*256 = 2560 = 0xA00) AV Register R/W
283 566 SetAnalog Write Analog DEC 1 = 256 (10 = 10*256 = 2560 = 0xA00) AV Register R/W
Table no. 23 Alarms Variables
DEC addres
Variable
name
Description / Variables Alarms States
Type Read [R]
/Write
[W]
BacNet Modbus BacNet Modbus
284 568 ResAl Resetting blocking alarms 0 – no resetting, 1 – resetting MSV
Coil 9088
R/W
285 570 A_Code Wrong application code alarm 0 – no alarm, 1 – alarm BV
Coil 9120
R
286 572 A_AF Fire alarm 0 – no alarm, 1 – alarm BV
Coil 9152
R
287 574 A_LowTemp Low supply temperature alarm 0 – no alarm, 1 – alarm BV
Coil 9184
R
288 576 A_ThHWair Anti-frost thermostat alarm 0 – no alarm, 1 – alarm BV
Coil 9216
R
289 578
A_3xThHWair
Anti-frost thermostat alarm (triple occurence of A_ThHWair alarm within an hour) 0 – no alarm, 1 – alarm BV
Coil 9248
R
290 580
A_ThHW water
Water heater return water low temperature alarm 0 – no alarm, 1 – alarm BV
Coil 9280
R
291 582
A_3xThHW
water
Water heater return water low temperature alarm (triple occurrence of
A_ThHWwater alarm within an hour)
0 – no alarm, 1 – alarm BV
Coil 9312
R
292 584 A_ThHE Electric heater thermostat alarm 0 – no alarm, 1 – alarm BV
Coil 9344
R
293 586 A_3xThHE Electric heater thermostat alarm (triple occurrence of the alarm within an houlr) 0 – no alarm, 1 – alarm BV
Coil 9376
R
294 588 A_ColdRec Recuperation frosting alarm 0 – no alarm, 1 – alarm BV
Coil 9408
R
295 590 A_Filter Dirty supply/exhaust lter alarm 0 – no alarm, 1 – alarm BV
Coil 9440
R
296 592 A_SupPres Supply fan alarm (tested by pressure gauge) 0 – no alarm, 1 – alarm BV
Coil 9472
R
297 594 A_VentFC Supply/exhaust fan inwerter alarm 0 – no alarm, 1 – alarm BV
Coil 9504
R
