125
18.5 Input coordinate data to current job
It allows user to input data to current working jobs.
Operation procedure Key Display
⑴ Under memory mode, choose “1.JOB”then press
ENT(or press numeric key 1), enter job
management screen.
“1. JOB”
+
ENT
Mem./ JOB
1. JOB selection
2. JOB deletion
3. Comms output
4. Comms input
5. Key in coord.
⑵ Choose current working job then select “5.Key
in coord.”then press ENT (or press numeric key 5),
enter coordinate data input function.
·On left upper corner it shows current jobname,
coordinate data quantity shows on right upper
corner.
“5. Key in
Coord.”
+
ENT
JOB2 14Rec
N： 0.000m
E： 0.000m
Z： 0.000m
Pt.： KOLIDA
REC. ↓
⑶ Input N, E, Z value, point name,code information
and press ENT key, press ▼key to show the second
page of input screen.
·Press ↓or↑key to read code from code Library.
Input
coordinate,
point name
and code
+
ENT
JOB2 14Rec
Code：
REC. ↓ ↑ ↑
⑷ Input finished, pressREC.to record data, enter the
next step of data input.
Finish all data input, press ESC, it returns to job
screen
REC.
JOB2 15Rec
N： 0.000m
E： 0.000m
Z： 0.000m
Pt. ： KOLIDA
REC. ↓
18.6 Registering Coordinate Data in Memory
· It is possible to register coordinate data in memory in advance. The coordinate data which has
been registered can be output during setting for use as instrument station, backsight station, known point,
and setting-out point coordinate data.
· Coordinate data is stored in a part of the memory separated from JOB data.
· It is possible to register 100,000 items of coordinate data, including the data inside the JOBs.
· There are two registration methods: key entry and entry from an external instrument.
