Kolida KTS440 R Series User Manual

37
8.3 Horizontal Angle Display Selection（Right /Left）
· It is possible to switch between Right Angle (horizontal angle clockwise) display and Left Angle
(horizontal angle counterclockwise) display.
· In advance allocate the function keys to display [R/L]. Refer to “18.1.1 Key Function Allocation”.
PROCEDURE
Operating Procedure Operation Display
⑴ In MEAS mode, display the screen in which
[HAR] is registered. Horizontal angle display
becomes [HAR].
Allocate
the
function
keys to
display
R/L
Meas. PC -30
PPM 0
3
ZA 89°59′54″
HAR 117°31′50″
P1
SD SHV R/L EDM
⑵ Press R/L, horizontal angle display switches
from [HAR] to [HAL].
HAL = 360°- HAR R/L
Meas. PC -30
PPM 0
3
ZA 89°59′54″
HAL 142°28′10″
P1
SD SHV R/L EDM
8.4 Horizontal Angle Repetition
· To find the horizontal angle with greater precision, perform repetition measurement.
·In advance allocate the function keys to display [REP]. Refer to “18.1.1 Key Function Allocation”.
