44
9.3 Distance and Angle Measurement
· KTS-440 allows to do angle measurement and distance measurement at the same time.
· When recording measurement data, see “17. Recording Distance Measurement Data”.
· Check the following once more before measuring a distance:
1 The KTS-440 is set up correctly over the surveying point.
2 The battery is full charged.
3 The horizontal and vertical circle indexing is completed.
4 The parameters are set in conformity with measurement conditions.
5 The atmospheric correction factor has been set, the prism constant correction value has
been set, the distance measurement mode has been selected.
6 The center of the target is correctly sight, the light intensity of the returned signal is
sufficiently high.
PROCEDURE S/H/V selection and distance measurement
Operating Procedure Operation Display
In the first page of MEAS Mode, press SHV,
to select the desired distance mode.
Each time SHV is pressed, the distance
measurement mode changes.
S: slope distance
H: horizontal distance
V: height difference
SHV
Meas. PC -30
PPM 0
3
S m
ZA 89°5954
HAR 117°3150
P1
SDIST SHV HSET EDM
Press SDIST, when measurement starts,
EDM information (distance mode, prism
constant correction value, atmospheric correction
factor, distance measurement method) is
represented by a flashing display.
SDIST
Dist.
Dist PC = -30
PPM = 0
Fine r
STOP
