⑵ Sight the foresight point, the displayed (HAR)
value is the included angle between 2 points.
Sight
Foresight
Point
Meas. PC -30
PPM 0
3
ZA 89°59′25″
HAR 86°40′23″
P2
SD SHV 0SET EDM
8.2 Setting the Horizontal Circle to a Required Value
8.2.1 Use HSET function to set a required direction value
· It allows you to set the instrument sight direction to and required direction value.
PROCEDURE
☆ Entry Rules
When you wish to enter 90°30′20″, input 90.3020.
When correct entered data,
Operating Procedure Operation Display
⑴ After sighting the target, from the MEAS
mode page 1, press HSET, enter the known
direction value. The right angle and left angle are
described as [HAR] and [HAL].
HSET
Set H angle
HAR：
B S
⑵ Enter the known direction value from
keyboard, press ENT, the entered known value
displayed.
Enter the
known
direction
value and
press
ENT
Set H angle
HAR：0.0100
B S
Meas. PC -30
PPM 0
3
ZA 89°59′54″
HAR 0°01′00″
P1
SDIST SHV HSET EDM
