Kolida KTS440 R Series User Manual

85
PROCEDURE
Operating Procedure Operation Display
⑴ In the “Resection Result Screen,” press
RE_OBS.
RE_OBS
Re-OBS
1. Start point
2. Last point
⑵ Select “1. Last point” or “2. Last point” and
press ENT. The following procedures are same
with the procedures after the steps 4 in “15.
RESECTION MEASUREMENT.”
Select
+
ENT
Resection Pt. 1
N 4456.343 3
E 4321.890
Z 215.557
Take the first point.
ANGLE DIST
15.2 Add Known Points
PROCEDURE
Operating Procedure Operation Display
⑴ Press ADD in the “Resection Result Screen”. ADD
N0 56.343
E0 21.890
Z0 15.557
dHD 0015 mm
dZ 0012 mm
RE_OBS ADD REC OK
⑵
When the former known points are not observed,
right upper screen is displayed.
When the observation for former known points is
finished, and some known points are in adding,
neither screen is displayed.
Resection Pt 4
N 4116.343
3
E 4021.840
Z 200.557
Please take the fourth point
ANGLE DIST
Resection Pt 4
N 0.000 m 3
E 0.000 m
Z 0.000 m
MEAS READ REC OK
