51
⑶ Press ENT to read in the selected point and
display the coordinate data.
ENT
N0 ： 1234.688
E0 ： 1748.234 3
Z0 ： 5121.579
Inst. h ： 1.600 m
Tgt. h ： 2.000 m
READ REC OK
⑷ Press OK，the coordinate Measurement
screen is displayed.
OK
Coordinate
1. OBS
2. Stn Data
3. Set H Angle
⑸Press ok, display comes back to coordinate
measurement screen.
确定
Coordinate measurement
1. Observation
2. Set station
3. set backsight
10.2 Azimuth Angle Setting
· After entering the coordinates of the instrument station point and backsight point, the backsight azimuth
angle can be calculated and set.
· Based on the instrument station coordinates and backsight station coordinates which have already been set.
Sight the backsight point, by a key operation, the azimuth angle of the backsight station will be
automatically set.
