151
20.1 Allocation and Registration
· It is possible to set new key allocations in the “Key Allocation Screen.”
When new key allocations are set, the content of the function keys in MEAS Mode are displayed. This
allocation is recorded in the instrument until they are set again.
It is possible to register two kinds of allocations: User setting 1 and User setting 2.
NOTE：When soft key allocations are recorded and registered, the previously recorded settings are cleared.
It is possible to allocate the functions displayed in the “Setting Mode Screen” to the soft keys. The
following functions can be allocated to the soft keys.
1) SD, HD, VD: Distance measurement.
2) SHV: Select distance mode (slope distance, horizontal distance, height difference)
3) 0set: Set horizontal angle to 0
4) H. ANG: Set required horizontal angle
5) R/L: Select horizontal angle right/Left
6) REP: Repetition Measurement
7) HOLD: Hold horizontal angle/ release horizontal angle
8) ZA/% : Switch between zenith angle/ slope in %
9) HT: Set the instrument height and target height
10）REC: Data recording
11）REM: REM measurement
12）MLM: Missing line measurement
13）RCL: Display final measurement data
14）View: Display observation data for the selected JOB
15）EDM: Distance measurement parameters setting (Atmospheric correction, prism constant correction,
distance measurement mode)
16）COORD: Coordinates measurement
17）S-O: Setting-out measurement
18）OFFSET: Offset measurement
19）MENU: To Menu Mode
20）RESEC: Resection measurement
21）DOUT: Output measurement results to external instrument
22）F/M: Switch between meters/feet
23）----: No functions set
