73
⑺ Press OK to return to the Offset
Measurement Menu Screen.
OK
Offset
1. Offset/Dist
2. Offset/Angle
3. Offset/2D
4. Stn data
12.3 Two-Distance Offset Measurement
·Install two offset points (1
st
target and 2
nd
target) on a straight line from the target point, observe the 1
st
target and 2
nd
target, then enter the distance between the 2
nd
target and the target point to find the target
point.
☆ NOTE：
1. The offset distance of Two-distance Offset Measurement depends on the distance between offset point 2
and target point on the line which consisted of target point, offset point 1and offset point 2.
2. Measure the distance from the target point to the 2
nd
target.
