24
6. EYEPIECE ADJUSTMENT AND OBJECT SETTING
·Method of Object Sighting（for reference）
① Sight the Telescope to the sky and rotate the eyepiece tube to make the reticle clear.
② Collimate the target point with top of the triangle mark on the collimator. (Keep a certain distance
between eye and the collimator).
③ Make the target image clear with the telescope focusing screw.
☆
If there is parallax when your eye moves up, down or left, right, that shows the
diopter of eyepiece lens or focus is not adjusted well and accuracy will be
influenced, so adjust the eyepiece tube carefully to eliminate the parallax.
7. POWER ON/OFF AND PREPARATION FOR MEASUREMENT
7.1 Power ON/OFF
PROCEDURE ·Power ON
Operation Display Note
Initializating…..
After power on, instrument process self-check as left.
Press
POWER
Meas. PC
-30
PPM
0
S 111.374 m 5
ZA 92°36′25″
HAR 120°30′10″ P1
SD SHIF Hset
Self-check ok.
·Power OFF
Hold POWER for 3seconds.
