9.5 Output Data to a Computer
·The data of distance measurement can be quickly output to a computer.
·In advance allocate the function key to display DOUT. For the allocation method, see “20.1.1 Key
Function Allocation.”
PROCEDURE
Operating Procedure Operation Display
⑴In MEAS mode, display the screen in which
DOUT is registered, press DOUT, following
screen is displayed.
DOUT
DOUT
1. Dist data
2. Angle data
⑵ Use ▲▼ to select “1. Dist data,” and press
ENT (or numeric key 1) to start distance
measuring. Then distance mode, prism constant
correction value, atmospheric correction factor，
distance measurement method are represented by
a flashing display.
select “1.
Dist data”
+
ENT
Dist.
Dist PC = -30
PPM = 0
Fine[s]
STOP
⑶ When distance measurement is completed, a
short beep sounds, and the measured distance
data(s), vertical angle (ZA), and horizontal
angle (HAR) are displayed. Then the measured
data begins being out put. When repeat fine
mode is selected, press STOP key to stop the
output.
Dist. PC -30
PPM 0
3
S 1234.569 m
ZA 89°59′54″
HAR 117°31′50″
P1
STOP
NOTE: When “2.Angle data” is selected in step 2, the angle data which is displayed on the screen can be
output.
10. COORDINATE MEASUREMENT
· After inputting instrument height and target height, it is possible to find the 3-dimensional coordinates for
the target based on station point coordinates.
