17
2. Menu Table ：
① MEAS mode menu
Name Function
_DIST Distance measurement
SHV Select distance mode (Select between slope distance, horizontal distance, height
difference)
0SET Set horizontal angle to 0
HSET Set known horizontal angle
R/L Select horizontal angle right/Left
REP Horizontal angle repetition measurement
HOLD Horizontal angle Hold/Release
ZA/％ Switch between Zenith angle / slope in ％
HT Set the instrument height and target height
REC Data recording
REM REM measurement
MLM MLM measurement
RCL Display final measurement data
VIEW Display observation data for the selected JOB
EDM Setting EDM (atmospheric correction and target, distance measurement mode
setting )
COORD Coordinates measurement
S-O Setting-out measurement
OFFSET Offset measurement
MENU To menu mode
RESEC Resection measurement
F/M Switch between meters/feet
D-OUT Output measurement result to external equipment
