77
⑵ Sight the target P2, then press MLM in the
third page of the “MEAS Mode Screen.”
MLM
MLM
Dist PC = 0
PPM = 0
Fine “S”
STOP
⑶ When the measurement is completed, the
“Missing Line Measurement Result Screen” is
displayed.
MLM S：Slope distance of the starting position
and 2nd target.
H：Horizontal distance of the starting position and
2nd target.
V：Height difference of the starting position and
2nd target.
S：Slope distance of the instrument station and
2nd target.
HAR：Horizontal angle of the instrument station
and 2nd target.
MLM S 20.757 m
H 27.345 m
3
V 1.020 m
S 15.483 m
HAR 135°31′28″
MLM MOVE SD OBS
⑷ Sight the target P 3 and press MLM. When
the observation is completed, the slope distance,
horizontal distance, and height difference from
between starting position P1 and target point P3.
It is possible to measure the slope distance,
horizontal distance, and height difference from
starting point to any other point using the same
procedure.
· Re-observe the starting point: OBS
MLM
MLM S 10.757 m
H 37.345 m
3
V 1.060 m
S 15.483 m
HAR 135°31′28″
MLM MOVE SD OBS
⑸ Press ESC to end the MLM measurement.
ESC
Meas. PC -30
PPM 0
S 11.678 m
ZA 59°39′54″
HAR 90°01′00″
P2
MLM REC MENU INST. H
To Next Page
